Specific surface area m2/g 9.74 | 3T powder compaction density g/cc 1.97 | Electrode compaction density g/cc 2.00 | Carbon content (%) 1.75 | 0.2C charge capacity (mAh/g) (2.0-3.6V) 113.00 | 0.2C discharge capacity (mAh/g) (2.0-3.6V) 101.00 | First cycle efficiency (%) 90.00 | 1C/0.2C capacity retention (%) 98.00 | 5C/0.2C capacity retention (%) 90.00

This equipment uses three-phase 380V/50Hz power supply with a rated power of 9kW. It features a single-temperature three-control structure with a temperature control accuracy of ±1°C. It is equipped with a Φ2-420mm K-type thermocouple sensor, with a maximum temperature of 1150°C and a recommended heating rate of 10°C/min. The temperature zone size is Φ150×905mm, and the furnace tube is made of 310S stainless steel with specifications of Φ60×1500mm. The equipment has a lifting angle range of 0-21 degrees, a stroke of 300mm, and a lifting speed of 5mm/s. The screw feeder reduction ratio is 10:1, and the furnace tube rotation reduction ratio is 25:1. Both the inlet and outlet tank volumes and the effective furnace tube volume are 3L. The gas circuit is equipped with a float flowmeter with a range of 0.1-1L/min, a Φ6.35 dual-ferrule connector for the gas inlet, and a Φ8 barb connector for the gas outlet. An overpressure safety valve is provided for automatic pressure relief protection.

The BMS for communication base station backup power is equipped with a 4G module, features short-circuit protection, and includes a balancing function to extend battery life, while also supporting remote monitoring.

The material of model TN-DC-1 is a black powder with uniform color, no agglomeration, and quasi-spherical particles. The single-point adsorption total pore volume is 1.0±0.05 cm³/g, the BET multi-point specific surface area reaches 2400±100 m²/g, the micropore proportion tested by the NLDFT model is not less than 90%, the average pore diameter is 1.7±0.1 nm, and the particle size D50 is 8.5±1.5 μm.

Powered by AC380V 50Hz power supply, rated power 13kW, equipped with a Φ2350mm K-type thermocouple sensor; maximum operating temperature 1200°C, long-term operating temperature 1150°C, recommended heating rate not exceeding 10°C/min, single-zone single-control mode, furnace chamber zone dimensions Φ350×420mm; reactor made of Hastelloy C276, dimensions Φ273×585mm, capable of accommodating a 2.3L corundum crucible with specifications Φ165×153mm; gas line equipped with a float flowmeter with a range of 0.3-3L/min, exhaust using an electric ball valve with KF25 interface, vacuum port also of KF25 specification, lifting device with a maximum stroke of 650mm; the complete system includes a glove box and furnace, as well as a glove box electrical control cabinet, with the glove box and furnace dimensions of 3500mm in length.
